TB WOODS SD158 QUICK DISCONNECT BUSHING
Quick Overview
Manufactured By: TB WOODS
Manufacturer Part Number: SD158
IMS Product Code: 1842685
Packaging: Sold Individually
Description:
TB Woods SD158 Quick Disconnect Bushing
Steel quick disconnect bushing with 1.625 inch bore diameter and 3.1875 inch flange outside diameter.
Specifications
- Bushing Size: SD
- Bore Type: Finished w/ Keyway
- Keyway Size: 3/8 x 3/16 in
- Bore Diameter: 1.6250 in
- Flange Outside Diameter: 3.1875 in
- Flange Thickness: 0.4375 in
- Length Through Bore: 1.8125 in
- Material: Steel
- Torque Capacity: 5000 in-lbs
- Screw Torque: 9 ft-lbs
- Barrel Diameter: 2-3/16 in
- Barrel Length: 1-3/8 in
- Bolt Circle Diameter: 2-11/16 in
- Number Of Bolt Holes: 3
- Screw Thread Size: 1/4-20 in
- Screw Length: 1-7/8 in
- Weight: 1.20 lbs
- Mounting Type: Conventional or Reverse
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 10 In Stock
Ships today if ordered in the next 10 hours and 2 minutes.
