TB WOODS SDS138 QUICK DISCONNECT BUSHING
Quick Overview
Manufactured By: TB WOODS
Manufacturer Part Number: SDS138
IMS Product Code: 1842575
Packaging: Sold Individually
Description:
TB Woods SDS138 Quick Disconnect Bushing
Steel quick disconnect bushing with 1-3/8 inch bore and 3.1875 inch flange outside diameter.
Specifications
- Bushing Size: SDS
- Bore Type: Finished w/ Keyway
- Keyway Size: 5/16 x 5/32 in
- Bore Diameter: 1.3750 in
- Flange Outside Diameter: 3.1875 in
- Flange Thickness: 0.4375 in
- Length Through Bore: 1.3125 in
- Material: Steel
- Torque Capacity: 5000 in-lbs
- Screw Torque: 9 ft-lbs
- Barrel Diameter: 2-3/16 in
- Barrel Length: 7/8 in
- Bolt Circle Diameter: 2-11/16 in
- Number Of Bolt Holes: 3
- Screw Thread Size: 1/4-20 in
- Screw Length: 1-3/8 in
- Mounting Type: Conventional or Reverse
