TB WOODS SK214 QD BUSHING
Quick Overview
Manufactured By: TB WOODS
Manufacturer Part Number: SK214
IMS Product Code: 2123031
Packaging: Sold Individually
Description:
TB Woods SK214 QD Bushing
Ductile iron quick disconnect bushing with 2-1/4 inch bore diameter, 3-7/8 inch flange diameter, and 7000 in-lb torque capacity.
Specifications
- Bushing Size: SK
- Bore Type: Finished Bore
- Bore Diameter: 2-1/4 in
- Flange Outside Diameter: 3-7/8 in
- Flange Thickness: 1/2 in
- Length Through Bore: 1.88 in
- Material: Ductile Iron
- Torque Capacity: 7000 in-lb
- Bolt Circle Diameter: 3.313 in
- Number Of Bolt Holes: 3
- Screw Thread Size: 5/16-18 in
- Screw Length: 2 in
- Keyway Size: 1/2 x 1/8 in
- Mounting Type: Conventional or Reverse
- Weight: 1.90 lbs
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 14 hours and 35 minutes.
