TB WOODS SK78 BUSHING
Quick Overview
Manufactured By: TB WOODS
Manufacturer Part Number: SK78
IMS Product Code: 1835802
Packaging: Sold Individually
Description:
TB Woods SK78 Bushing
Cast iron quick disconnect bushing with 7/8" bore and keyway.
Specifications
- Bushing Size: SK
- Bore Type: Finished w/ Keyway
- Keyway Size: 3/16 x 3/32 in
- Bore Diameter: 0.8750 in
- Flange Outside Diameter: 3.8750 in
- Flange Thickness: 0.5000 in
- Length Through Bore: 1.8750 in
- Material: Cast Iron
- Torque Capacity: 7000 in-lbs
- Screw Torque: 15 ft-lbs
- Barrel Diameter: 2-13/16 in
- Barrel Length: 1-3/8 in
- Bolt Circle Diameter: 3-5/16 in
- Number Of Bolt Holes: 3
- Screw Thread Size: 5/16-18 in
- Screw Length: 2 in
- Weight: 3.40 lbs
- Mounting Type: Conventional or Reverse
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
Ships today if ordered in the next 8 hours and 15 minutes.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 8 hours and 15 minutes.
