TB WOODS SKL178 QUICK DISCONNECT BUSHING
Quick Overview
Manufactured By: TB WOODS
Manufacturer Part Number: SKL178
IMS Product Code: 1792052
Packaging: Sold Individually
Description:
TB Woods SKL178 Quick Disconnect Bushing
Ductile iron bushing with finished bore and keyway, used for quick disconnect applications.
Specifications
- Bushing Size: SKL
- Bore Type: Finished Bore
- Keyway Size: 1/2 x 1/4 in
- Bore Diameter: 1-7/8 in
- Flange Outside Diameter: 3.8750 in
- Flange Thickness: 0.5000 in
- Length Through Bore: 1.1250 in
- Material: Ductile Iron
- Torque Capacity: 7000 in
- Screw Torque: 15 ft-lbs
- Bolt Circle Diameter: 2-3/8 in
- Number Of Bolt Holes: 3
- Screw Thread Size: 1/4 in
- Screw Length: 1-1/2 in
- Weight: 0.90 lbs
- Mounting Type: Conventional
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
