TE CONNECTIVITY 1SNK505010R0000 ZS4 TERMINAL BLOCK
Quick Overview
Manufactured By: TE CONNECTIVITY
Manufacturer Part Number: 1SNK505010R0000
IMS Product Code: 2130271
Packaging: Box of 50
Description:
TE Connectivity 1SNK505010R0000 ZS4 Terminal Block
ZS4 grey terminal block with screw clamp connection. Rated for 1000V AC/DC (IEC). 2 positions. Connects conductors up to 4mm˛ (12AWG).
Specifications
- Number of Positions: 2
- Wire Size: 24 AWG to 12 AWG
- Connection Method: Screw
- Rated Current: 32 A (IEC)
- Rated Voltage: 1000 V (IEC)
- Pitch: 5.2 mm
- Color: Grey
- Housing Material: Polyamide (PA)
- Operating Temperature: -55 to 110 degrees C
- Protection Rating: IP20
- Flammability Rating: UL94 V-0
- Dimensions: 47.3 mm x 53 mm x 5.2 mm (D x H x W)
- Weight: 8.8 g
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
