TELEMECANIQUE 9013GHG2J30X PRESSURE SWITCH
Quick Overview
Manufactured By: TELEMECANIQUE
Manufacturer Part Number: 9013GHG2J30X
IMS Product Code: 2177635
Packaging: Sold Individually
Description:
Telemecanique 9013GHG2J30X Pressure Switch
Electromechanical pressure switch for controlling electrically driven water pumps and air compressors, with adjustable differential setting between 80-100 psi.
Specifications
- Pressure Sensor Name: 9013GH
- Type of Operation: Regulation between 2 thresholds
- Pressure Actuator: Diaphragm
- Scale Type: Adjustable differential
- Contacts Type and Composition: 2 NC, snap action, DPST-DB, Form YY
- Electrical Connection: Screw-clamp terminals
- Materials in Contact with Fluid: Zinc plated steel or equivalent flange, nitrile (Buna-N) or equivalent rubber diaphragm
- Fluid Connection Type: 0.25 inch NPSF internal conforming to UL 508
- Housing Material: Polypropylene
- Operating Position: Any position
- NEMA Degree of Protection: NEMA 1
- IP Degree of Protection: IP20
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 1 hours and 26 minutes.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 1 hours and 26 minutes.
