More Views
T&B 8404 HEAVY SERVICE EVER-LOK RECEPTACLE
Quick Overview
Manufactured By: THOMAS & BETTS
Manufacturer Part Number: 8404
IMS Product Code: 1498171
Packaging: Sold Individually
Description:
T&B 8404 Heavy Service Ever-Lok Receptacle
Heavy Service Locking Receptacle, 480 VAC, 30 A, 60 Hz, 3 Pole, 4 Wires, Cast Aluminum
Specifications
- Amperage Rating: 30 A
- Application: For general industrial, lighting connections, indoor welding stations, machinery/tool connections, power distributions panels, convenience power and battery charging equipment
- Application Type: Indoor industrial and heavy-duty use
- Approvals: CSA, UL
- Built-In Strain Relief: No
- Color: gray
- Compliant with standard(s): UL CSA
- Connection Type: Receptacle
- Current Rating: 30 A
- Design: back box screw cover
- Frequency: 60 Hz
- Frequency Rating: 60 Hz
- Gross Weight: 2.6 lbs
- Lockout-Tagout: No
- Main function: Connector (Receptacle)
- Manufacturer product status: Commercialized
- Material: Cast Aluminum
- Net Weight: 2.85 lbs
- Number of Poles: 3
- Number of Wires: 4
- Operating Temperature: -40-203 degrees F
- Product Series: DuraTite and Ever-Lok
- Product series / family name: Ever-Lok Series
- Rated Voltage (DC): 250Vdc
- Rated current: 30A
- Rated voltage (AC): 480Vac
- Shape: angled adapter
- Type: Heavy Service
- UNSPSC Code: 39121404
- Voltage: 480 V
- Voltage Rating: 480 V AC
Request A Quote
Let us know your requirements and an IMS Supply representative will provide you with a detailed quote.
Shipping Times Provided In Quote
