TIMKEN 314K RADIAL BALL BEARING
Quick Overview
Manufactured By: TIMKEN
Manufacturer Part Number: 314K
IMS Product Code: 2163799
Packaging: Sold Individually
Description:
Timken 314K Radial Ball Bearing
Deep groove radial ball bearing for general industrial applications, 70 mm bore, 150 mm OD, 35 mm width, open, without snap ring.
Specifications
- Bore Diameter: 70 mm
- Outside Diameter: 150 mm
- Bearing Width: 35 mm
- Ball Material: Alloy Steel
- Cage Material: Steel
- Dynamic Radial Load Capacity: 115654 N
- Static Radial Load Capacity: 68058 N
- Limiting Speed - Grease: 2730 rpm
- Limiting Speed - Oil: 3180 rpm
- Maximum Temperature: 120 degrees C
- Minimum Temperature: -50 degrees C
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 13 hours and 35 minutes.
