TIMKEN 36KDD RADIAL BALL BEARING
Quick Overview
Manufactured By: TIMKEN
Manufacturer Part Number: 36KDD
IMS Product Code: 1924034
Packaging: Sold Individually
Description:
Timken 36KDD Radial Ball Bearing
Radial/Deep Groove Ball Bearing - Straight Bore, 6 mm ID, 19 mm OD, 6 mm Width, Double Shielded, Without Snap Ring
Specifications
- Bore Type: Straight
- Bore Diameter: 6 mm
- Outside Diameter: 19 mm
- Overall Width: 6 mm
- Closure Type: Double Shielded
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Internal Clearance: P
- Max Operating Temperature: 120 degrees C
- Precision Rating: Not Rated
- Finish Coating: Uncoated
- Bearing Material: Steel
- Cage Material: Steel
- Inner Ring Width: 0.236 in
- Fillet Radius: 0.012 in
- Series: 30 metric Extra small
- Radial Dynamic Load Capacity: 570 lbf
- Radial Static Load Capacity: 204 lbf
- Weight: 0.022 lbs
- Type Of Bearing: Ball Bearing
- Component Type: Assembly
- Outer Diameter Type: Cylindrical
- Precision Class: ABEC1
- Relubricatable: No
- Rolling Element: Ball
- Min Operating Temperature: -50 degrees C
- Self Aligning: No
- Retainer Material: Cold Rolled Steel
- Product Type: Radial & Deep Groove Ball Bearings
- Bore / Inner Diameter Inch: 0.236
- Bore / Inner Diameter MM: 6
- Seal Type: 2 Metal Shields
- Snap Ring: No
- Internal Fit / Preload: C3
- Snap Ring Groove: No
- Outer Race Width Inch: 0.236
- Outer Race Width MM: 6
- Static Load Capacity: 195lbs.
