TIMKEN ER18 BALL BEARING
Quick Overview
Manufactured By: TIMKEN
Manufacturer Part Number: ER18
IMS Product Code: 1908734
Packaging: Sold Individually
Description:
Timken ER18 Ball Bearing
Insert Ball Bearing; Imperial Series; 1.1250in Bore; 2.4409in OD; 1.5423in Width; Double Sealed; Cylindrical Bore; Steel Bearing; Steel Cage; Setscrew Locking; Black Oxide Coated
Specifications
- Bore Type: Cylindrical bore
- Bearing Type: Ball Bearing
- Material: Bearing Steel
- Lubrication Type: Relubricatable
- Outside Diameter D: 2.441 in
- Inner Ring Width B: 1.547 in
- Outside Ring Width C: 0.875 in
- Radius r: 0.024 in
- Center of Bearing from End S: 0.625 in
- Dimension S1: 0.922 in
- Dimension F: 1.578 in
- Dimension J: 0.344 in
- Dimension M: 0.219 in
- Dimension D1: 2.641 in
- Dimension T: 0.063 in
- Dimension X: 0.797 in
- Dimension Y: 0.75 in
- Set Screw Size: M6x1
- Number of Set Screws: 2
- Angle between Set Screws: 90 degrees
- Static Load Rating: 2530 lbf
- Dynamic Load Rating: 4850 lbf
- Seal Type: Narrow Shroud
- Basic Outer Ring Size: 206
- Sub Series: ER
- Seal Material: Nitrile Rubber
- Maximum Temperature: 250 degrees F
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 13 hours and 21 minutes.
