TOSHIBA 0014SDSR41A-P 1HP MOTOR
Quick Overview
Manufactured By: TOSHIBA
Manufacturer Part Number: 0014SDSR41A-P
IMS Product Code: 2118844
Packaging: Sold Individually
Description:
Toshiba 0014SDSR41A-P 1HP Motor
1 HP, 1800 RPM, 230/460V, 143T Frame, TEFC Enclosure, Cast Iron, Footed Mount
Specifications
- Type: AC Induction Motor
- Duty: High-performance inverter duty and severe duty
- Horsepower: 1 HP
- Phase: 3 Phase
- Voltage: 230/460V
- Speed: 1800 RPM
- Enclosure: TEFC
- Frame: 143T
- Material: Cast Iron
- Mounting: Footed
- Service Factor: 1.15
- Full Load Amp Draw: 3.4/1.7 A
- Shaft Diameter: 0.875 in
- Weight: 51 lbs
- Insulation Class: Class F
- Temperature Rating: 40 degrees C
- Torque Rating: 2.98 ft-lb
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 3 In Stock
Ships today if ordered in the next 11 hours and 47 minutes.
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 2 In Stock
Ships today if ordered in the next 11 hours and 47 minutes.
