TSUBAKI H60B15F-1-5/8 FINISHED BORE SPROCKET
Quick Overview
Manufactured By: TSUBAKI
Manufacturer Part Number: H60B15F-1-5/8
IMS Product Code: 1835613
Packaging: Sold Individually
Description:
Tsubaki H60B15F-1-5/8 Finished Bore Sprocket
Finished Bore Sprocket - 60 / 3/4 in, Finished w/ Keyway, 1.6250 in Bore , 15 Teeth, Steel, Hardened Teeth Material
Specifications
- Product Type: Finished & Machinable Bore Roller Chain Sprockets
- Chain Number & Pitch: 60 / 3/4 in
- Number Of Teeth: 15
- Bore Type: Finished w/ Keyway
- Bore Diameter: 1.6250 in
- Number Of Strands Across: 1
- Material: Steel
- Hardened Teeth: With Hardened Teeth
- Number Of Hubs: 1
- Length Through Bore: 1.2500 in
- Outside Diameter: 3.9780 in
- Pitch Type: Single
- Pitch Diameter: 3.608 in
- Tooth Width: 0.459 in
- Weight: 2.30 lbs
