TURCK RI360P0-QR24M0-IOLX2-H1141 CONTACTLESS ENCODER
Quick Overview
Manufactured By: TURCK
Manufacturer Part Number: RI360P0-QR24M0-IOLX2-H1141
IMS Product Code: 2131940
Packaging: Sold Individually
Description:
Turck RI360P0-QR24M0-IOLX2-H1141 Contactless Encoder
Contactless encoder with IO-Link interface, absolute semi-multiturn output, hollow shaft, and compact rugged housing.
Specifications
- Technology: Contactless
- Output Type: Absolute semi-multiturn
- Shaft Type: Hollow shaft
- Shaft Diameter: 6, 6.35, 9.525, 10, 12, 12.7, 14, 15.875, 19.05, 20 mm
- Operating Voltage: 15…30 VDC
- Communication Protocol: IO-Link
- Electrical Connection: Connector, M12 x 1
- Housing Material: Metal/plastic, ZnAlCu1/PBT-GF30-V0
- Ambient Temperature: -25…+85 °C
- Protection Class: IP68/IP69K
- Construction Size: 81 x 78 x 24 mm
- Flange Type: Flange without mounting element
- Measuring Range: 0…360°
- Weight: 326 g
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 2 In Stock
Ships today if ordered in the next 13 hours and 57 minutes.
