UNITED ELECTRIC J21K-232 DIFFERENTIAL PRESSURE SWITCH
Quick Overview
Manufactured By: UNITED ELECTRIC
Manufacturer Part Number: J21K-232
IMS Product Code: 2149260
Packaging: Sold Individually
Description:
United Electric J21K-232 Differential Pressure Switch
Differential pressure switch with SPDT output, 0-25 PSID adjustable range, 1/4" NPT connection, and gasketed epoxy-coated diecast aluminum enclosure.
Specifications
- Direction: Uni-Directional
- Measurement: PSID
- Media Compatibility: Liquid, Gas
- Range: ±50 psi
- Connection Size: 1/4 in
- Contact Type: SPDT
- Connection: 1/4" NPT
- Accuracy: 1%
- Housing Material: Metallic
- Measurement Range: 0 - 25 PSID
- Contact Rating: 15 A
- Set Point Range: 0 - 25 psi
- Power Required: Switch
- Enclosure Rating: NEMA 4X
- Approvals: CE Approved, UL Listed
- Supply Voltage (Nominal): 480 VAC
- Unit Weight: 2.00 lbs
- Country of Origin: USA
- Overall Width: 4-1/4 in
- Overall Height: 6-9/16 in
- Overall Depth: 2-11/16 in
- Maximum Operating Temperature: 160 degrees F
- Minimum Operating Temperature: -40 degrees F
- Standards: ATEX Directive (94/9/EC); CE; CUL; UL Listed
- Adjustable Range: 0 to 25 PSID
- Working Pressure: 30" HgVac to 110 PSI
- Proof Pressure: 25 PSI
- Deadband: 0.6 to 1 PSI
- Bellows Material: Phosphor Bronze
- Pressure Connections: 1/4" NPTF
- Enclosure Material: Gasketed Epoxy-Coated Diecast Aluminum
- Switch Output: 1 SPDT
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 11 hours and 43 minutes.
