US MOTORS 1864 DIRECT DRIVE BLOWER MOTOR
Quick Overview
Manufactured By: US MOTORS
Manufacturer Part Number: 1864
IMS Product Code: 2163797
Packaging: Sold Individually
Description:
US Motors 1864 Direct Drive Blower Motor
Permanent Split Capacitor direct drive blower motor, 1/3 HP, 115V, 1075 RPM, 5.6" diameter
Specifications
- HP: 1/3
- Voltage: 115
- RPM: 1075
- Speeds: 3
- Amps: 5.0
- Phase: 1
- Rotation: Reversible
- Bearings: Ball
- Capacitor MFD: 7.5
- Enclosure Type: OAO (Open Air Over)
- Frame: 48Y
- Hz: 60
- Insulation Class: B
- Maximum Ambient Temperature: 40 degrees C
- Mounting: Band/Hub/Stud
- Service Factor: 1.00
- Thermal Protection: Automatic
- Body Diameter: 5.6 in
- Shaft Diameter: 1/2 in
- Shaft Length: 5 in
- Length Less Shaft: 5-21/32 in
- Overall Length: 10-21/32 in
- Weight: 11 lb
- Frame Material: Steel
