VERIS TWLH50B WALL TEMPERATURE SENSOR
Quick Overview
Manufactured By: VERIS INDUSTRIES
Manufacturer Part Number: TWLH50B
IMS Product Code: 1863012
Packaging: Sold Individually
Description:
Veris TWLH50B Wall Temperature Sensor
Black ABS Plastic 10 kOhm T3 Thermistor NTC Temperature Sensor with LCD Display, 10 kOhm Setpoint with Push Button Override
Specifications
- Application Zone: Living Space
- Application: Wall
- Color: Black
- Dimension Depth: 1.2" (30 mm)
- Dimension Height: 4.8" (122 mm)
- Dimension Width: 3.5" (89 mm)
- Display Size: 1.2" x 0.6" (30.5 mm x 14 mm)
- Display Type: LCD
- Electrical Wiring Size: 24 - 18 AWG (0.22 - 0.75 mm²)
- Enclosure Material: ABS Plastic
- Measurement Type: Temperature
- Mounting: Wall
- Operating Temperature: 32 - 122 degrees F (0 - 50 degrees C)
- Outputs: Resistive output
- Override: Yes
- Product Certification: CE
- Product Type: Sensor
- Range: TW
- Setpoint: Yes
- Supply Voltage AC Nominal: 24 VAC
- Supply Voltage DC Range: 12 - 30 VDC
- Temperature Calibration Certificate: None
- Temperature Measurement Accuracy: ±0.4 degrees F (±0.2 degrees C)
- Temperature Measurement Range: 32 - 158 degrees F (0 - 70 degrees C)
- Temperature Sensor Type: 10k Ohm Type 3 Thermistor
