VIKING FBI-1A ANTI-FEEDBACK PAGING INTERFACE
Quick Overview
Manufactured By: VIKING
Manufacturer Part Number: FBI-1A
IMS Product Code: 2160314
Packaging: Sold Individually
Description:
Viking FBI-1A Anti-Feedback Paging Interface
Eliminates feedback "squeal" when paging. Includes high-quality digital message storage, adjustable alert tone volume, and N.O./N.C. relay contacts. Compatible with most paging and telephone systems.
Specifications
- Power: 120VAC / 13.8VAC 1.25A
- Dimensions: 5.25" x 3.5" x 1.75" (133mm x 89mm x 44mm)
- Operating Temperature: 32�F to 90�F (0�C to 32�C)
- Humidity: 5% to 95% non-condensing
- Sampling Rate: 80K / 40K (equivalent)
- Maximum Page Length: 16 / 32 seconds
- Output Impedance: 600 Ohm
- Maximum Audio Output: 2V RMS across 600 Ohms
- Talk Battery: 24VDC
- DPDT Relay Contact Rating: 1A @ 30VDC / 0.5A @ 125VAC, 250VAC maximum
- Connections: (13) cage clamp screw terminals
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 12 hours and 35 minutes.
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 2 In Stock
Ships today if ordered in the next 12 hours and 35 minutes.
