WAGO 231-306/107-000 6-POLE FEMALE CONNECTOR
Quick Overview
Manufactured By: WAGO
Manufacturer Part Number: 231-306/107-000
IMS Product Code: 1752498
Packaging: Sold Individually
Description:
Wago 231-306/107-000 6-Pole Female Connector
6-pole female connector with screw flange, CAGE CLAMP connection technology, pin spacing 5.08 mm, orange color
Specifications
- pole count: 6
- pin spacing: 5.08 mm
- connection method: Push-in/CAGE CLAMP
- rated voltage: 320 V (III/3), 630 V (II/2)
- rated current: 16 A
- conductor size: 0.08-2.5 mm² / 28-12 AWG
- wire stripping length: 8-9 mm
- material: Polyamide (PA66), Copper alloy
- color: orange
- flammability class: V0
- operating temperature: -40 to 105 °C
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships today if ordered in the next 14 hours and 4 minutes.
