WATLOW PM6C1EA-AAAAAAA PID TEMPERATURE CONTROLLER
Quick Overview
Manufactured By: WATLOW
Manufacturer Part Number: PM6C1EA-AAAAAAA514147
IMS Product Code: 2145592
Packaging: Sold Individually
Description:
Watlow PM6C1EA-AAAAAAA PID Temperature Controller
1/16 DIN Panel Mount LCD Display, Pushbutton Setting, Relay Contact Output
Specifications
- Operating Voltage: 100 ~ 240VAC
- Output #1: Mechanical Relay 5A, Form C
- Universal Input: thermocouple grounded or ungrounded, RTD 2-wire or 3-wire, 0-20mA or 0-50mV
- Universal Process Output: range selectable between 0-10VDC or 4-20mA
- Series: PM PLUS
- Mounting Type: Panel Mount 1/16 DIN
- Display Type: LCD
- Primary Function: PID Controller
- Temperature Sensor Input Type: Universal
- Power Supply: AC
- Output 1: Relay Contact
- Front Panel IP/NEMA Rating: NEMA 4X, IP66 and IP67
- Operating Temperature: -18 to 65 degrees C
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 2 In Stock
Ships today if ordered in the next 10 hours and 3 minutes.
