WEG 00236ET3ER145TC-S 2 HP MOTOR
Quick Overview
Manufactured By: WEG
Manufacturer Part Number: 00236ET3ER145TC-S
IMS Product Code: 2147723
Packaging: Sold Individually
Description:
Weg 00236ET3ER145TC-S 2 HP Motor
Three-phase general purpose motor with TEFC enclosure, 2 HP output at 3600 RPM, 230/460V voltage rating, 143/5TC frame size, footless C-face mount, continuous duty.
Specifications
- Motor Phase: 3 ph
- Motor Horsepower: 2 hp
- Synchronous Rpm: 3600 rpm
- Motor Supply Voltage: 190/380//208-230/460 V
- Frame Size: 143/5TC
- Enclosure Type: TEFC (Totally Enclosed Fan Cooled)
- Frequency Rating: 50/60 Hz
- Duty Condition Type: Continuous Duty
- Mounting Type: C-Face / Footless
- Full Load Current: 5.46-4.94/2.47 A
- Full Load Efficiency: 85.50 %
- Service Factor: 1.15
- Frame Material: Rolled Steel
- Insulation Class: F
- IP Rating: 55
- Standards Met: UL, CSA, CE
- Weight: 43.45 lbs
