WEG 01536ET3E254TC-W22 15 HP MOTOR
Quick Overview
Manufactured By: WEG
Manufacturer Part Number: 01536ET3E254TC-W22
IMS Product Code: 2146566
Packaging: Sold Individually
Description:
Weg 01536ET3E254TC-W22 15 HP Motor
Three-phase TEFC motor with 15 HP output at 3600 RPM, 208-230/460V, 254/6TC frame, cast iron construction, and NEMA Premium Efficiency rating.
Specifications
- Motor Phase: 3 ph
- Motor Horsepower: 15 hp
- Synchronous Rpm: 3600 rpm
- Motor Supply Voltage: 190/380//208-230/460 V
- Frame Size: 254/6TC
- Enclosure Type: TEFC (Totally Enclosed Fan Cooled)
- Frequency Rating: 50/60 Hz
- Duty Condition Type: Continuous Duty
- Mounting Type: C-Face / Foot
- Full Load Current: 17.20 A
- Full Load Efficiency: 91.00 %
- Service Factor: 1.25
- Frame Material: Cast Iron
- Insulation Class: F
- IP Rating: 55
- Standards Met: UL, CSA, CE
- Weight: 288.80 lbs
