YOKOGAWA UT35A TEMPERATURE CONTROLLER
Quick Overview
Manufactured By: YOKOGAWA
Manufacturer Part Number: UT35A
IMS Product Code: 2135393
Packaging: Sold Individually
Description:
Yokogawa UT35A Temperature Controller
1/4 DIN temperature controller with universal input, relay output, and RS-485 communication.
Specifications
- PV Input: 1 Universal input (TC, RTD, mV, V, mA)
- Indication Accuracy: ±0.1% of F.S.
- Control Scan Period: 200 msec
- Control Outputs (MV): Relay, Voltage Pulse, Current
- Algorithm: ON/OFF, PID (Continuous, Time-proportional), Heating/Cooling, Position-proportional
- Digital Inputs: 2 (Std) 7 (Max)
- Digital Outputs: 3 (Std) 8 (Max)
- Power Supply: 100 to 240 VAC (+10%, -15%) or 24 VAC/DC (+10%, -15%) (option)
- Power Consumption: Max 18 VA
- Mass: Max 0.5 kg
- Depth from Panel Surface: 65 mm
- Display: 14-segment, 5 digits, Bar graph LCD display
- Communication: RS-485, Ethernet
- Dust and Waterproof Level of Front Panel: NEMA4 (IP66)
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships on Monday, September 29, 2025
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
