ABB 2CDS273334R0487 CIRCUIT BREAKER
Quick Overview
Manufactured By: ABB
Manufacturer Part Number: 2CDS273334R0487
IMS Product Code: 2145692
Packaging: Sold Individually
Description:
ABB 2CDS273334R0487 Circuit Breaker
3-pole miniature circuit breaker with K tripping characteristic, 20A current rating, 240/480Vac voltage rating, DIN rail mounting.
Specifications
- Maximum Amperage: 20 A
- Number of Poles: 3
- Voltage: 240/480Vac
- Mounting Style: DIN Rail
- Current Rating: 20A
- Number of Phases: 3
- Material: Plastic, Copper
- Type: Main Breaker
- Tripping Characteristics: Type K
- Current Type: AC/DC
- Control Style: Switch
- Number of Ports: 3
- Extended Product Type: ST203M-K20
- Product ID: 2CDS273334R0487
- Standards: CSA 22.2 No. 235, IEC/EN 60947-2, UL 1077
- Tripping Characteristic: K
- Power Loss: 5.4 Wat Rated Operating Conditions per Pole 2.7 W
- Rated Ultimate Short-Circuit Breaking Capacity (Icu): (400 V AC) 15 kA
- Rated Service Short-Circuit Breaking Capacity (Ics): (400 V AC) 11.2 kA
- Terminal Type: Double Clamp
- Product Net Width: 52.5 mm
- Product Net Depth / Length: 69 mm
- Product Net Height: 88 mm
- Product Net Weight: 0.345 kg
