ABB DCS800-S02-0520-05 DC DRIVE
Quick Overview
Manufactured By: ABB
Manufacturer Part Number: DCS800-S02-0520-05-0
IMS Product Code: 2146427
Packaging: Sold Individually
Description:
ABB DCS800-S02-0520-05 DC Drive
DC Variable Frequency Drive, 125 HP, 485 Amps, 3-Phase, 200-240VAC or 400-480VAC Input, 500VDC Output
Specifications
- Series: DCS800
- Input Voltage: 200-240VAC, 400-480VAC
- Output Voltage: 500VDC
- Amperage: 485 Amps
- Frequency: 50-60 Hz
- Frame Size: D3
- Width: 11 in
- Height: 18 in
- Depth: 12 in
- Weight: 55 lbs
- Operating Modes: 4 Quadrant (Regen), 4 Quadrant (Reversing)
- Analog Inputs: 2 Inputs (-10 - 10 VDC / 4 - 20 mA), 2 Inputs (-10 - 10 VDC)
- Analog Outputs: 1 Output (4 VDC for Armature Current), 2 Outputs (4 - 20 mA)
- Control Inputs: 1 Input (Digital Encoder), 8 Inputs (NPN)
- Control Outputs: 1 Output (Relay), 7 Outputs (NPN)
- Integrated Keypad: Yes
