ADVANTECH ADAM-6052-D 8DI/8DO IOT MODBUS ETHERNET REMOTE I/O
Quick Overview
Manufactured By: ADVANTECH
Manufacturer Part Number: ADAM-6052-D
IMS Product Code: 2156145
Packaging: Sold Individually
Description:
Advantech ADAM-6052-D 8DI/8DO IoT Modbus Ethernet Remote I/O
16-Channel Source-Type Isolated Digital I/O Modbus TCP Module, 8 Digital Inputs/8 Digital Outputs
Specifications
- Channels: 8
- Connectors: 1 x RJ45, 1 x 13-pin plug-in screw terminal, 1 x 9-pin plug-in screw terminal
- Protocol: Modbus/TCP, TCP/IP, UDP, HTTP, DHCP, MQTT, SNMP, ASCII command
- Interface: Ethernet
- Max. Input Frequency: 3 kHz
- Input Voltage: Dry Contact Logic level 0: close to GND Logic level 1: open Wet Contact Logic level 1: 10~30 VDC Logic level 0: 0~3 VDC
- Isolation Voltage: 2,000 VDC
- Operating Temperature: -40~70 degrees C (-40~158 degrees F)
- Output Type: Source
- Output Voltage: 10~35 VDC
- Sink Current: 1 A max./channel
- Weight: 0.50 LBS
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 11 In Stock
Ships on Monday, June 1, 2026
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
