ALLEN BRADLEY 1336S-BRF50-AN-EN5-L6 ADJUSTABLE FREQUENCY AC DRIVE

Starting At: $595.00

Quick Overview

Manufactured By: ALLEN BRADLEY
Manufacturer Part Number: 1336S-BRF50-AN-EN5-L6
IMS Product Code: 2161517
Packaging: Sold Individually

Description:

Allen Bradley 1336S-BRF50-AN-EN5-L6 Adjustable Frequency AC Drive

The Allen Bradley 1336S-BRF50-AN-EN5-L6 adjustable frequency drive is designed for precise motor control applications. It functions effectively with a frequency tolerance of 48 to 62 Hz, ensuring stable operation during varying load conditions.

Specifications

  • Voltage: 380/480V
  • Frequency: 50/60HZ
  • Amps: 10.7
  • HP: 5
  • Weight: 15.00 lbs (6.80 kg)
  • Frequency Tolerance: 48-62 Hz
  • AC Input Overvoltage Trip: 570V AC
  • AC Input Undervoltage Trip: 280V AC
  • Bus Overvoltage Trip: 810V DC
  • Bus Undervoltage Trip: 400V DC
  • Nominal Bus Voltage: 648V DC
  • Constant Torque - Input kVA: 6.6-8.0
  • Input Amps: 10.7
  • Output kVA: 7.2
  • Output Amps: 9.0
  • Variable Torque - Input kVA: 7.0-8.5
  • Power Ride-Thru: 15 milliseconds at full load
  • Logic Control Ride-Thru: 0.5 seconds minimum, 2 seconds typical
  • Ground Fault Trip: Phase-to-ground on drive output
  • Voltage Tolerance: -10% of minimum, +10% of maximum
  • kW: 3.7 kW
  • Current: 8.4 A
  • Enclosure: IP00


Used:
A previously used, fully functional product that may have some signs of cosmetic wear.

Availability: 1 In Stock

Ships on Monday, June 1, 2026

Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.


Product images shown are for illustration purposes only and may not be an exact representation of the product you will receive. IMS Supply is not an authorized distributor, reseller or representative of Allen Bradley. All product names, trademarks, brands and logos used on this site are the property of their respective owners and are used for identification purposes only.
