ALLEN BRADLEY 1746-IG16 TTL INPUT MODULE
Quick Overview
Manufactured By: ALLEN BRADLEY
Manufacturer Part Number: 1746-IG16
IMS Product Code: 147753
Packaging: Sold Individually
Description:
Allen Bradley 1746-IG16 TTL Input Module
SLC 500 Digital DC TTL Input Module with 16 input channels, operating at 4.5-5.5V DC.
Specifications
- input channels: 16
- voltage range: 4.5-5.5 Volts DC
- chassis slot: single
- Operating Voltage: +5V to DC COM: 4.5 to 5.5VDC (sourcing), 50mV peak to peak ripple (max)
- Backplane Current Consumption: 0.140A @ 5VDC, 0.0A @ 24VDC
- Max Signal Delay: ON: 0.25ms, OFF: 0.50ms
- Off-State Voltage: 2 to 5.5VDC
- Off-State Current: 4.1mA max
- Nominal Input Current: 3.7mA @ 5VDC
- Weight: 0.23 kgs
- Controller Platform: SLC 500
- working voltage category: 5V DC TTL sourcing signal input
- number of inputs: 16
- operating voltage: 4.5-5.5V DC (sourcing)
- maximum peak to peak ripple: 50mV
- backplane current at 5V: 0.14A
- backplane current at 24V: 0A
- maximum signal delay ON: 0.25ms
- maximum signal delay OFF: 0.5ms
- maximum off state voltage: 2V DC
- maximum off state current: 4.1mA
- nominal input current: 3.7mA at 5V DC
- thermal dissipation rating: 0.02W per point with a minimum of 0.7W and a total of 1W
