ALLEN BRADLEY 1761-L32BWA MICROLOGIX 1000 PLC
Quick Overview
Manufactured By: ALLEN BRADLEY
Manufacturer Part Number: 1761-L32BWA
IMS Product Code: 148048
Variation: Unspecified
Unspecified
Series: A
Series: E
Packaging: Sold Individually
Description:
Allen Bradley 1761-L32BWA MicroLogix 1000 PLC
Programmable controller with 32 I/O channels, 1K EEPROM, 120-240V AC power supply.
Specifications
- Dimensions: 7.87 x 2.87 x 3.15 inches
- I/O Channels: 32
- EEPROM: 1 K
- Data Words: 437
- Instruction Words: 737
- Power Supply Voltage: 85 to 264 Volts AC
- Frequency: 47 to 63 Hertz
- Ambient Operating Temperature (Horizontal): 0 to 55 degrees Celsius
- Ambient Operating Temperature (Vertical): 0 to 40 degrees Celsius
- Weight: 1.10 lbs
- Number of Outputs: 12
- Number of Inputs: 20
- Input Type: DC
- Output Type: Relay
- Mounting Style: Din Rail Mount
- Communication Ports: RS-232C / RS-485
- Terminal Style: Screw Clamp Terminals
- Series: E
Request A Quote
Let us know your requirements and an IMS Supply representative will provide you with a detailed quote.
Shipping Times Provided In Quote
