ARMSTRONG 75AI2 FLOAT & THERMOSTATIC STEAM TRAP
Quick Overview
Manufactured By: ARMSTRONG
Manufacturer Part Number: 75AI2
IMS Product Code: 1836361
Packaging: Sold Individually
Description:
Armstrong 75AI2 Float & Thermostatic Steam Trap
Float and thermostatic steam trap with 1/2-inch NPT connection, rated for 75 PSIG maximum operating pressure. Constructed from cast iron with an inline connection configuration.
Specifications
- Body Material: Cast Iron
- Capacity: 200 - 1,870 #/hr
- Connection Orientation: Straight Thru Inlet & Outlet
- Connection Size: 1/2 in
- Connection Type: NPT
- Face to Face Dimension: 5 in
- Integral Vacuum Breaker: No
- Maximum Allowable Pressure (MAP): 175 PSIG
- Maximum Operating Pressure (MOP): 75 PSIG
- Maximum Allowable Temperature: 377 degrees F
- Orifice Size: 11/64 in
- Type: Float & Thermostatic
- Weight: 9.75 lbs
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships today if ordered in the next 14 hours and 25 minutes.
