BALDOR IDXM7542T 3HP EXPLOSION PROOF MOTOR
Quick Overview
Manufactured By: BALDOR ELECTRIC
Manufacturer Part Number: IDXM7542T
IMS Product Code: 2125536
Packaging: Sold Individually
Description:
BALDOR IDXM7542T 3HP Explosion Proof Motor
Explosion proof AC motor for hazardous locations, 3HP, 1755RPM, 3PH, 230/460V, 182TC frame, TEFC enclosure.
Specifications
- Catalog Number: IDXM7542T
- Enclosure: TEFC
- Frame: 182TC
- Frame Material: Cast Iron
- Frequency: 60 Hz
- Phase: 3
- Synchronous Speed: 1800 RPM
- Voltage: 230/460 V
- Horsepower: 3
- RPM: 1755
- Service Factor: 1.00
- Insulation Class: F
- Duty Rating: Continuous
- Efficiency: 89.5%
- Agency Approvals: UL, CSA
- Ambient Temperature: 40 degrees C
- Mounting: Foot Mounted
- Shaft Diameter: 1.125 in
- Overall Length: 18.24 in
- Weight: 140-146 lbs
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
