BALDOR JM3555 2HP 3PH MOTOR
Quick Overview
Manufactured By: BALDOR
Manufacturer Part Number: JM3555
IMS Product Code: 2147658
Packaging: Sold Individually
Description:
Baldor JM3555 2HP 3PH Motor
Three Phase AC Motor, 2HP, 3450RPM, 230/460V, 56J Frame, TEFC Enclosure
Specifications
- AC Phase: Three Phase
- Ambient Temperature: 40 C
- Amperage Rating: 5.4/2.7 A
- Bearing Type: Ball
- Duty Rating: CONT
- Efficiency: 80
- Enclosure Type: TEFC
- Frame: 56J
- Frame Material: Steel
- Frequency Rating: 60 Hz
- Full Load Amps: 2.7
- Full Load Speed: 3450
- Horsepower: 2 hp
- Insulation Class: B
- Mounting Arrangement: F1
- Nema Design: B
- Number of Poles: 2
- Output: 2 HP
- Phase: 3
- Power Factor: 87
- Rated Load (HP): 2
- Rotation: Reversible
- Shaft Diameter: 0.625 IN
- Shaft Extension Location: Pulley End
- Speed: 3450 rpm
- Synchronous Speed: 3600 RPM
- Voltage: 230/460 V
