BANNER ES-FA-11AA SAFETY RELAY MODULE
Quick Overview
Manufactured By: BANNER ENGINEERING CORP.
Manufacturer Part Number: ES-FA-11AA
IMS Product Code: 1733810
Packaging: Sold Individually
Description:
Banner ES-FA-11AA Safety Relay Module
Safety relay module for E-stop, rope pull, and interlock applications with 24 V ac/dc supply voltage, 1 dual/single channel safety input, and 2 NO safety outputs rated at 7 A.
Specifications
- Supply Voltage: 24 V ac/dc
- Safety Input: 1 Dual/Single Channel
- Safety Output: 2 NO, 7 A
- Aux Output: 1 NC, 7 A
- Terminal Block: Removable
- IP Rating: IP20
- Dimension (H x W x D): 84 x 22.5 x 118 mm
- Max Operating Temperature: 50 degrees C
- Response Time: 25 ms typical
- Power Consumption: 2 W / 2 VA
- Mechanical Life: 20 million operations
- Electrical Life: 1,000,000 cycles @ 450 VA
- PL Rating: e
- SIL Rating: 3
- Safety Category Rating: 4
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
