BANNER LE250KQ LASER DISPLACEMENT SENSOR
Quick Overview
Manufactured By: BANNER ENGINEERING CORP.
Manufacturer Part Number: LE250KQ
IMS Product Code: 2131148
Packaging: Sold Individually
Description:
Banner LE250KQ Laser Displacement Sensor
Laser displacement sensor with 100-400 mm range, 12-30 V dc input, push/pull and PNP outputs, Class 2 laser, and M12 integral quick disconnect.
Specifications
- Supply Voltage: 12-30 V dc
- Sensing Mode: Triangulation
- Max Sensing Distance: 400 mm
- Min Sensing Distance: 100 mm
- Output Type: 1 NPN/PNP Configurable; 1 PNP
- Laser Classification: Class 2
- Connection Type: Integral QD
- Quick Disconnect Type: M12
- Number of Pins: 5
- Adjustments: Push Button; Remote Teach
- Min Operating Temperature: -20 degrees C
- Max Operating Temperature: 55 degrees C
- IP Rating: IP67
- NEMA / UL Type Rating: NEMA 4X
- Primary Housing Material: Zinc Alloy Die-Cast
- Min Response Time: 2 ms
- Max Ambient Light: 10000 lux
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships on Monday, October 6, 2025
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
