BANNER LX6EQ EMITTER
Quick Overview
Manufactured By: BANNER ENGINEERING CORP.
Manufacturer Part Number: LX6EQ
IMS Product Code: 2132090
Packaging: Sold Individually
Description:
Banner LX6EQ Emitter
Photoelectric Sensor, Standard Range, 10-30V DC, NPN/PNP Output, 0-6m Sensing Range, 1ms Response Time
Specifications
- Cable Length: 0.15m
- IP Rating: IP65
- NEMA Rating: NEMA 4X
- Sensing Mode: Emitter
- Housing Material: Aluminum
- Max Sensing Range: 2000mm
- Array Length: 143mm
- Connection: Pigtail QD
- Minimum Object Detection: 9.5mm
- Quick Disconnect Type: M12
- Number of Pins: 5
- Supply Voltage: 10-30V DC
- Output Type: NPN/PNP
- Response Time: 1.6ms ON, 7ms OFF
- Lens Material: Acrylic
- Indicator: LEDs
- Operating Temperature: -20 to 70C
- Operating Humidity: 90% @ 50C
- Weight: 0.66 lbs
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 2 In Stock
Ships on Monday, October 6, 2025
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 2 In Stock
Ships on Monday, October 6, 2025
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
