BANNER QS186LE212Q5 LASER SENSOR
Quick Overview
Manufactured By: BANNER ENGINEERING CORP.
Manufacturer Part Number: QS186LE212Q5
IMS Product Code: 2131982
Packaging: Sold Individually
Description:
Banner QS186LE212Q5 Laser Sensor
QS18 Series Laser Class 2 Photoelectric Sensor, 15m range, 10-30V DC input, M12 pigtail QD connector
Specifications
- Power: DC
- Sensing Beam: Visible Red Laser
- Cable Length (m): 0.15
- IP Rating: IP67
- NEMA / UL Type Rating: NEMA 4X
- Supply Voltage: 10-30 V dc
- Sensing Mode (General): Opposed
- Sensing Mode (Detailed): Laser Emitter
- Housing Style: Rectangular w/M18 Mount
- Primary Housing Material: ABS
- Laser Classification: Class 2
- Max Sensing Distance (mm): 15000
- Connection: Pigtail QD
- Quick Disconnect Type: M12
- Min Op. Temp. (C): -10
- Max Op. Temp. (C): 50
- Delay at Power-up (ms): 10
- Number of Pins: 4
- Max Op. Relative Humidity [%]: 95% @ 50C
- Lens Material: PMMA
- Barrel Diameter (mm): 18
- Indicator: LEDs
- Opposed Mode Emitter/Receiver: Emitter
- Feature: Quick Disconnect: Yes
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
