BANNER QS30LLPQ POLARIZED RETROREFLECTIVE SENSOR
Quick Overview
Manufactured By: BANNER ENGINEERING CORP.
Manufacturer Part Number: QS30LLPQ
IMS Product Code: 2064708
Packaging: Sold Individually
Description:
Banner QS30LLPQ Polarized Retroreflective Sensor
Polarized retroreflective sensor with visible red laser, 10-30 V DC supply, bipolar NPN/PNP outputs, and M12 integral quick disconnect.
Specifications
- Power: DC
- Sensing Beam: Visible Red Laser
- Sensing Mode: Retroreflective - Polarized
- Max Sensing Distance: 18000 mm
- Supply Voltage: 10-30 V dc
- Outputs: Bipolar (NPN & PNP)
- Connection: Integral QD
- Quick Disconnect Type: M12
- Number of Pins: 5
- IP Rating: IP67
- NEMA Rating: NEMA 4X
- Housing Style: Rectangular w/M30 Mount
- Primary Housing Material: Thermoplastic
- Laser Classification: Class 1
- Min Op. Temp.: -10 degrees C
- Max Op. Temp.: 50 degrees C
- Output response time: 0.5 ms
- Delay at Power-up: 1000 ms
- Repeatability: 70 µs
- Max Op. Relative Humidity: 95% @ 50°C
- Lens Material: Acrylic
- Barrel Diameter: 30 mm
- Indicator: Bargraph
- Adjustments: Teach Button
- Operation: Light/Dark Operate
- Sensing Beam Wavelength: 650
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
