BANNER SLLP23-910P88 SAFETY LIGHT CURTAIN
Quick Overview
Manufactured By: BANNER ENGINEERING CORP.
Manufacturer Part Number: SLLP23-910P88
IMS Product Code: 2160989
Packaging: Sold Individually
Description:
Banner SLLP23-910P88 Safety Light Curtain
EZ-SCREEN LS safety light curtain pair with 23 mm resolution, 12 m range, 910 mm defined area, black housing, 8-pin M12 pigtail QD, 2x OSSD, EDM, Fault Out
Specifications
- Resolution: 23 mm
- Operating Range: 0.1 - 12 m
- Defined Area Height: 910 mm
- Supply Voltage: 24 V dc
- IP Rating: IP65, IP67
- Safety Level: Type 4
- PL Rating: Ple
- SIL Rating: SIL3; CL3
- Response Time: 15.9 ms
- Operating Temperature: -20 to +55 deg. C
- Relative Humidity: 95%
- Housing Material: Aluminum
- Dimensions WxD: 36 x 45 mm
- Overall Length: 914 mm
- Number of Pins: 8
- Connector Type: M12 Pigtail (Yellow)
- OSSD Rating: 24 V dc at 0.5 A each
- Supply Current: 115 mA Typical
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 3 In Stock
Ships today if ordered in the next 1 hours and 17 minutes.
