BANNER SLLP23-980P88 SAFETY LIGHT CURTAIN
Quick Overview
Manufactured By: BANNER ENGINEERING CORP.
Manufacturer Part Number: SLLP23-980P88
IMS Product Code: 2160992
Packaging: Sold Individually
Description:
Banner SLLP23-980P88 Safety Light Curtain
23 mm resolution safety light curtain with 980 mm defined area and 12 m operating range. Type 4 safety level, IP65/IP67 rated housing, and 24 VDC supply voltage.
Specifications
- Resolution: 23 mm
- Defined Area Height: 980 mm
- Operating Range: 0.1 - 12 m
- Safety Level: Type 4
- IP Rating: IP65, IP67
- Supply Voltage: 24 VDC
- Response Time: 16.7 ms
- System Type: Emitter/Receiver Pair
- Number of Pins: 8
- Operating Temperature: -20 to 55 degrees C
- Relative Humidity: 95%
- OSSD Rating: 24 VDC at 0.5 A each
- Overall Length: 983 mm
- Housing Material: Aluminum
- Housing Finish: Black Anodized
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
Ships today if ordered in the next 1 hours and 17 minutes.
