BANNER SSA-EB1PL-02ECQ5A 30MM EMERGENCY STOP PUSHBUTTON

Starting At: $75.00

Quick Overview

Manufactured By: BANNER ENGINEERING CORP.
Manufacturer Part Number: SSA-EB1PL-02ECQ5A
IMS Product Code: 2145598
Packaging: Sold Individually

Description:

Banner SSA-EB1PL-02ECQ5A 30mm Emergency Stop Pushbutton

30mm mount emergency stop pushbutton with 40mm red actuator, solid illuminated base, IP65 rating, 2 NC contacts, and 5-pin M12 integral quick disconnect.

Specifications

  • Connection Type: M12
  • Armed Color (Solid): OFF
  • Actuated Color: Red
  • Illumination Type: Base
  • Button Shroud: No
  • IP Rating: IP65
  • Supply Voltage: 12-30 V dc
  • Housing Style: Base
  • Device Type: Push Button
  • Primary Housing Material: Polycarbonate
  • In-Series Diagnostics: No
  • Actuation: Twist/Pull-to-Release
  • Connection: Integral QD
  • Feature: Illuminated
  • Feature: Quick Disconnect
  • Mounting Thread/Style: 30 mm
  • Contact Quantity: 2 NC
  • Contact Rating: 2 A @ 24 V dc
  • Button Diameter (mm): 40
  • Actuator/Button Material: Thermoplastic
  • Dimensions (HxWxD mm): 120 x 80
  • Min Operating Temperature: -25 degrees C
  • Max Operating Temperature: 55 degrees C


New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.

Availability: 1 In Stock

Ships today if ordered in the next 4 hours and 58 minutes.

Product images shown are for illustration purposes only and may not be an exact representation of the product you will receive. IMS Supply is not an authorized distributor, reseller or representative of Banner Engineering Corp.. All product names, trademarks, brands and logos used on this site are the property of their respective owners and are used for identification purposes only.
