BANNER VS25EVQ OPPOSED MODE EMITTER
Quick Overview
Manufactured By: BANNER ENGINEERING CORP.
Manufacturer Part Number: VS25EVQ
IMS Product Code: 2062098
Packaging: Sold Individually
Description:
Banner VS25EVQ Opposed Mode Emitter
VS2 Series Ultra Thin Miniature Sensor, Emitter, 1200mm max sensing distance, 10-30V DC supply voltage, IP67 rating, M8 quick disconnect
Specifications
- Power: DC
- Sensing Beam: Visible Red LED
- IP Rating: IP67
- NEMA / UL Type Rating: NEMA 4X
- Supply Voltage: 10-30 V dc
- Sensing Mode (General): Opposed
- Sensing Mode (Detailed): Emitter
- Housing Style: Rectangular
- Primary Housing Material: Thermoplastic
- Max Sensing Distance (mm): 1200
- Connection: Pigtail QD
- Quick Disconnect Type: M8
- Min Op. Temp. (C): -20
- Max Op. Temp. (C): 55
- Output response time (ms): 1 ON/0.5 OFF
- Sensing Beam Wavelength: 660
- Delay at Power-up (ms): 100
- Repeatability (µs): 100
- Number of Pins: 3
- Max Op. Relative Humidity (%): 80% @ 50°C
- Lens Material: MABS
- Indicator: LEDs
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
