BANNER QS18VP6LLP PHOTOELECTRIC SENSOR
Quick Overview
Manufactured By: BANNER
Manufacturer Part Number: QS18VP6LLP
IMS Product Code: 1817518
Packaging: Sold Individually
Description:
Banner QS18VP6LLP Photoelectric Sensor
Photoelectric sensor with PNP output and 0.1-10 m sensing distance.
Specifications
- Power: DC
- Sensing Beam: Visible Red Laser
- Cable Length: 2 m
- IP Rating: IP67
- NEMA / UL Type Rating: NEMA 4X
- Supply Voltage: 10-30 V dc
- Sensing Mode: Retroreflective/Polarized
- Housing Style: Rectangular w/M18 Mount
- Primary Housing Material: ABS
- Laser Classification: Class 1
- Input/Output: Discrete
- Max Sensing Distance: 10000 mm
- Outputs: PNP
- Connection: Cable
- Operation: Light/Dark Operate
- Min Op. Temperature: -10 C
- Max Op. Temp.: 50 C
- Output response time: 0.7 ms
- Sensing Beam Wavelength: 650
- Delay at Power-up: 200 ms
- Repeatability: 130 µs
- Number of Pins: 4
- Max Op. Relative Humidity: 95% @ 50°C
- Lens Material: Acrylic
- Adjustments: Potentiometer
- Barrel Diameter: 18 mm
- Indicator: LEDs
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
