BANNER SMI306EQ PHOTOELECTRIC SENSOR EMITTER
Quick Overview
Manufactured By: BANNER
Manufacturer Part Number: SMI306EQ
IMS Product Code: 1899726
Packaging: Sold Individually
Description:
Banner SMI306EQ Photoelectric Sensor Emitter
SMI30 Series Intrinsically Safe Barrel Sensor Emitter, Frequency A, 140m range, 10-30VDC, Infrared LED, IP67 rating
Specifications
- Supply Voltage: 10-30 V dc
- Sensing Beam: Infrared LED
- Max Sensing Distance: 106680 mm
- IP Rating: IP67
- NEMA / UL Type Rating: NEMA 4X
- Housing Style: Barrel
- Barrel Diameter: 30 mm
- Primary Housing Material: Thermoplastic
- Lens Material: Acrylic
- Connection: Integral QD
- Quick Disconnect Type: 7/8 in. (Mini)
- Number of Pins: 3
- Min Op. Temperature: -40 C
- Max Op. Temp.: 70 C
- Max Op. Relative Humidity: 90% @ 50C
- Output response time: 10 ms
- Repeatability: 1000 µs
- Special Feature: Intrinsically Safe
- Special Feature: Encapsulated
- Feature: Hazardous Area
- Feature: Quick Disconnect
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 12 hours and 58 minutes.
