BROOK CROMPTON BC4N1.5V4 1.5HP MOTOR
Quick Overview
Manufactured By: BROOK CROMPTON
Manufacturer Part Number: BC4N1.5V4
IMS Product Code: 2147300
Packaging: Sold Individually
Description:
Brook Crompton BC4N1.5V4 1.5HP Motor
1.5HP, 1800RPM, 230/460V, TEFC, Cast Iron, NEMA 145T Foot Mounted Motor
Specifications
- Enclosure: TEFC
- Frame: 145T
- HP: 1.5
- Hz: 60
- Phase: 3
- RPM: 1800
- Voltage: 230/460
- Type: General Purpose
- Horsepower (hp): 1.5
- KW: 1.1
- Speed (rpm): 1750
- Voltage Rating (VAC): 230/460
- Frequency Rating (Hz): 60
- Mounting Type: Foot
- NEMA Design: B
- Nom Efficiency: 86.5
- Insulation Class: F
- KVA Code: K
- Service Factor: 1.25
- FLA: 4.2/2.1
- Frame Material: Cast Iron
- Torque Rating(ft-lb): 4.50
- Duty: S1
- DE Bearing: 6205ZZC3
- NDE Bearing: 6203ZZC3
- Ambient Temp: -20 to 40 degrees
- Rotation: Reversible
- Number of Leads: 9
- Orientation: Horizontal or Vertical
- Poles: 4
- Power Factor: 0.78
- C-Dimension (inch): 14.2
- Shaft Length (inch): 2.25
- Shaft Size (inches): 0.875
- Weight: 67 lbs
- Country Of Origin: China
