BROWNING VF4E-224 FOUR BOLT FLANGE BALL BEARING
Quick Overview
Manufactured By: BROWNING MFG
Manufacturer Part Number: VF4E-224
IMS Product Code: 2147697
Packaging: Sold Individually
Description:
Browning VF4E-224 Four Bolt Flange Ball Bearing
Four bolt flange ball bearing unit with 1.5 inch bore diameter, cast iron housing, eccentric collar locking device, and single lip contact seal with flinger.
Specifications
- Bore Diameter: 1.5 in
- Housing Material: Cast Iron
- Locking Device: Eccentric Collar
- Seal Type: Single Lip Contact Seal with Flinger
- Overall Length: 5.125 in
- Overall Height: 2.313 in
- Overall Width: 5.125 in
- Bolt Size: 0.5 in
- Max Rpm: 3500 rpm
- Radial Dynamic Load Capacity: 7340 lbf
- Radial Static Load Capacity: 4467 lbf
- Operating Temperature Range: -20 to 200 F
- Weight: 5.83 lbs
- Series: VF4E
