BROWNING 2BK160H V-BELT PULLEY
Quick Overview
Manufactured By: BROWNING
Manufacturer Part Number: 2BK160H
IMS Product Code: 2148780
Packaging: Sold Individually
Description:
Browning 2BK160H V-Belt Pulley
Cast iron V-belt pulley with 2 grooves, split taper bushing, 15.75 in outside diameter
Specifications
- Belt Section Size: 4L, 5L, A, B
- Number Of Grooves: 2
- Outside Diameter: 15.7500 in
- Bore Type: Split Taper Bushed
- Bushing Series: H
- Bore Diameter: Bushing Required
- Keyway Size: 1/4 x 1/16 (1-1/4 Bore) in, 1/4 x 1/8 (15/16 to 1-3/16 Bore) in, 1/8 x 1/16 (1/2 to 9/16 Bore) in, 3/16 x 3/32 (5/8 to 7/8 Bore) in, 3/8 x 1/16 (1-3/8 to 1-1/2 Bore) in, 5/16 x 1/16 (1-5/16 to 1-3/8 Bore) in
- Material: Cast Iron
- Length Through Bore: 1.2500 in
- Face Width: 1.7500 in
- Bushing Bore Range: 0.500 - 1.500 in
- Datum Diameter: 15.0000 in (A) 15.4000 in (B)
- Pitch Diameter: 15.2000 in (A) 15.7000 in (B)
- Pulley Construction: Plain
- Weight: 20.19 lbs
