BROWNING Q1 1 1/8 SPLIT TAPER BUSHING
Quick Overview
Manufactured By: BROWNING
Manufacturer Part Number: Q1 1 1/8
IMS Product Code: 1842035
Packaging: Sold Individually
Description:
Browning Q1 1 1/8 Split Taper Bushing
Split Taper Bushing, 1-1/8 in Bore, 4.1250 in Flg OD, 2.5000 in LTB, Steel Material
Specifications
- Bushing Size: Q1
- Bore Type: Finished Bore
- Keyway Size: 1/4 x 1/8
- Bore Diameter: 1-1/8 in
- Material: Steel
- Flange Outside Diameter: 4.1250 in
- Flange Thickness: 17/32 in
- Flange Type: Solid Flange
- Length Through Bore: 2.5000 in
- Barrel Diameter Large End: 2-7/8 in
- Screw Torque: 348 in
- Barrel Diameter Small End: 2.7657 in
- Bolt Circle Diameter: 3-3/8 in
- Number Of Bolt Holes: 3
- Screw Thread Size: 3/8 in
- Screw Length: 1-1/4 in
- Mounting Type: Conventional
- Weight: 4.36
