BROWNING VF2S-116 FLANGE BALL BEARING UNIT
Quick Overview
Manufactured By: BROWNING
Manufacturer Part Number: VF2S-116
IMS Product Code: 1954305
Packaging: Sold Individually
Description:
Browning VF2S-116 Flange Ball Bearing Unit
Two-Bolt Flange Ball Bearing Unit with 1 in Bore, Cast Iron Housing, Set Screw Locking, Single Lip Contact Seal
Specifications
- Bore Diameter: 1 in
- Housing Material: Cast Iron
- Duty Type: Intermediate Duty
- Bolt Center To Center Length: 3.8910 in
- Overall Length: 4.8750 in
- Locking Device: Set Screw
- Expansion Type: Non-Expansion Bearing (Fixed)
- Seal Type: Single Lip Contact Seal
- Overall Height: 1.3906 in
- Housing Width: 0.9531 in
- Lubrication Type: Lithium Complex NLGI 2 Grease
- Overall Width: 2.7500 in
- Bore Type: Straight
- Inner Ring Width: 1.1090 in
- Bearing Material: 52100 Bearing Steel
- Radial Dynamic Load Capacity: 2801 lbf
- Radial Static Load Capacity: 1651 lbf
- Length Through Bore: 1.1090 in
- Operating Temperature Range: -20 to 200 F
- Max Operating Temperature: 200 F
- Bolt Size: 0.4375 in
- Max Rpm: 3500 rpm
- Series: VF2S
- Weight: 1.26 lbs
- Type Of Bearing: Ball
- Mounting Type: 2-Bolt Flange
