CARLO GAVAZZI DAA01CM24 DELAY ON OPERATE TIMER
Quick Overview
Manufactured By: CARLO GAVAZZI
Manufacturer Part Number: DAA01CM24
IMS Product Code: 2125431
Packaging: Sold Individually
Description:
Carlo Gavazzi DAA01CM24 Delay on Operate Timer
Timer Delay on Operate DIN rail mount 22.5x80x99.5mm Euronorm housing selectable time ranges 0.1s - 100h Supply voltage 24-240Vac and 24Vdc Screw terminals connection 8A SPDT relay output
Specifications
- type of module: timer
- counting range: 0.1s...100h
- kind of output: SPDT
- output 1 electrical parameters: 24V DC / 5A, 250V AC / 8A
- number of operation modes: 1
- counter operation modes: delayed switching on
- electrical connection: screw terminals
- mounting: for DIN rail mounting
- operating temperature: -20...60 degrees C
- body dimensions: 22.5x80x99.5mm
- ip rating: IP20
- supply voltage: 24V DC, 24...240V AC
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
