CLEVELAND CONTROLS AFS-222 DIFFERENTIAL PRESSURE SWITCH
Quick Overview
Manufactured By: CLEVELAND CONTROLS
Manufacturer Part Number: AFS-222
IMS Product Code: 1877186
Packaging: Sold Individually
Description:
Cleveland Controls AFS-222 Differential Pressure Switch
Adjustable air pressure sensing switch with SPDT contacts, used to sense positive, negative, or differential air pressure in HVAC and energy management applications.
Specifications
- Set Point Range: 0.05 - 12 in WC
- Measurement: Inches of Water Column
- Media Compatibility: Air
- Connection Size: 1/4 in
- Type: Adjustable
- Connection: Barbed
- Contact Rating: 15 A
- Contact Type: SPDT
- Approvals: UL, FM, CSA, CE
- Operating Temperature: -40 to 180°F (-40° to 82°C)
- Operating Humidity: 10 to 90% Non-condensing
- Wetted Parts: Silicone
- Process Connection: 1/8" FNPT, 1/4" compression, 1/4" barb
- Mounting: Surface mount
- Dimensions: 4"W x 6.13"H x 3.56"D
- Weight: 1.2 lb
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 3 In Stock
Ships today if ordered in the next 15 hours and 1 minutes.
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 6 In Stock
Ships today if ordered in the next 15 hours and 1 minutes.
Used (Special):
The part has tube attached to the side of the part.
Availability: 2 In Stock
Ships today if ordered in the next 15 hours and 1 minutes.
